3M™ Diamond Resin Wheel 664BK, 1A1, 12X.472X5, X=1/2 D126 664BK-MMMRBDW18490

Name: 3M™ Diamond Resin Wheel 664BK, 1A1, 12X.472X5, X=1/2 D126 664BK-MMMRBDW18490
Brand: 3M
SKU: 7010498113

SKU

#7010498113

Call for Availability

For industrial/occupational use only. Not for consumer sale or use.

3M industrial and occupational products are intended, labeled, and packaged for sale to trained industrial and occupational customers for workplace use. Unless specifically stated otherwise on the applicable product packaging or literature, these products are not intended, labeled, or packaged for sale to or use by consumers (e.g., for home, personal, primary or secondary school, recreational/sporting, or other uses not described in the applicable product packaging or literature), and must be selected and used in compliance with applicable health and safety regulations and standards (e.g., U.S. OSHA, ANSI), as well as all product literature, user instructions, warnings, and other limitations, and the user must take any action required under any recall, field action, or other product use notice. Misuse of 3M industrial and occupational products may result in injury, sickness, death, or property damage. For help with product selection and use, consult your on-site safety professional, industrial hygienist, or other subject matter expert.

Our 3M™ Diamond Resin Wheel 664BK is used for high performance grinding of carbide cutting tools. It has superior form retention and runs with water-based coolant. From 100 to 400 mesh grits and dual grit - (120/320).

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Specifications

More Information
Specification(s)
Brand	3M
Abrasive Material	Diamond
Product Form	Wheel
Product Number	664BK
Wheel Type	1A1
Country Of Origin	US
Shipping Quantity	1.0
UPC Code	0000000000000

Product Information

Cut Faster, Finish Better

These resin bonded diamond wheels are designed for high performance grinding on carbide. The 3M™ Diamond Resin Wheel 664BK line is specifically designed for the production and sharpening of cutting tools, including end work, gashing and cutting primary and secondary relief edges. Primary relief involves removing material directly behind the cutting edge to enhance chip clearance. For secondary relief, a slight bevel is ground next to the primary relief. End work grinds a small relief angle on the tip of the tool, while gashing adds a slot along the cutting face to allow for chip flow.

Resin Bonds Designed for the Application

These superabrasive wheels also use a resin bond, a fast cutting, resilient and inexpensive bond with high resistance to heat. Resin bonds are more able to disperse heat away from the cutting surface through the coolant. They are excellent for precision work on tool metals like carbide. This also allows for faster cuts and a higher cut rate. Use in wet grinding applications with high volume flood coolant systems on CNC or offhand applications.

The Right Wheel for the Job

3M™ Superabrasive Wheels are available in a variety of constructions, each with its own unique characteristics.

The correct combination of cutting speed, feed rate, and conditioning interval are essential in order to fully utilize the performance offered by a grinding wheel.

3M provides a broad portfolio of superabrasive feature a variety of metal cores, including aluminum, steel, composite and copper, and can be cut with custom arbor holes to fit customer specifications. From short runs and re-sharpening to "lights-out" and long production runs, 3M has the wheel design to meet your needs.

Diamond abrasive has unsurpassed cutting ability on hard materials like cemented carbide, carbons and ceramics

Durable resin bond has good mineral adhesion and resists heat, extending wheel life

Designed for high form retention over long runs

Various wheel designs are available for gashing, primary and secondary relief and end work, arbor holes are made to customer specifications

Use with water-based coolant
