KNIPEX - 10" Pliers Wrench
KNIPEX - 10" Pliers Wrench
$63.13
/ Each
SKU
#KN-10846815
Part #:
8603250SBA
Ships in 3-4 Days
- Replaces a full set of inch and metric open end wrenches up to 2" (52 mm)
- Smooth jaws for damage free installation of plated fittings - working directly on chrome
- Adjustable tightening tool
- Excellent for gripping, holding, pressing and bending applications
- Zero backlash jaw surface pressure prevents damage to edges of sensitive components
- 19 adjustment positions at the touch of a button directly on the workpiece
- Laser-etched scale allows the wrench opening to be set before gripping onto workpiece - metric and inch markings
- Parallel jaws allow infinitely variable gripping of all widths to the specified maximum size
- Reliable catching of the hinge bolt: no unintentional shifting
- The action of the jaws allows bolted connections to be tightened and released quickly using the ratchet principle
- Lever transmission greater than 10-1 for strong gripping power
- Chrome vanadium electric steel; forged, oil-hardened
| Specification(s) | |
|---|---|
| Part Number | 86 03 250 SBA |
| Video Link | https://www.youtube.com/watch?v=KN64Qw2l8nE |
| UPCs | 843221000110 |
| COO | Germany |
| Harmonized Tariff Code | 8204.12.0000 |
| ECCN | EAR99 |
| UNSPSC | 27112112.0 |
| Nominal Length | 10" |
| Tool Width | 2" |
| Tool Height | 11/16" |
| Tool Weight | 1.18 |
| Packaging Length | 14 1/4" |
| Packaging Width | 4 1/8" |
| Packaging Height | 1" |
| Packaging Weight | 1.075 |
| 1000 Volt Insulated | No |
| Material Type | Chrome vanadium electric steel, forged, oil-hardened |
| Handle Type | Plastic coating |
| Handle Length | 8" |
| Color | Red |
| Tip Thickness | 5/16" |
| Number of Adjustment Positions | 19 |
| Max Jaw Opening - Hex | 2" |
| Max Jaw Opening - Working Capacity | 2" |
| Reach | does not contain SVHC |
| RoHS | not applicable |
| Data Sheet | https://s3-us-west-2.amazonaws.com/catsy.534/Pliers+Wrench+Product+Family+Data+Sheet+ALL+SBA.pdf |
| Catalog Page PDF | https://s3-us-west-2.amazonaws.com/catsy.534/USCAT19_86_Pliers+Wrenches.pdf |
| Tool Nominal Length-Decimal | 10" |
| Tool Width-Decimal | 1.95" |
| Tool Height-Decimal | 0.7" |
Safety Data Sheets (PDF , 0B)
Pliers Wrench. Replaces a full set of inch and metric open end wrenches up to 2" (52 mm).
