KNIPEX - 6 1/4" Angled Electricians' Shears
KNIPEX - 6 1/4" Angled Electricians' Shears
$41.17
/ Each
SKU
#KN-14673981
Part #:
950520US
Ships in 3-4 Days
- The 45° angled shears provides a natural extension of your hand which offers a more comfortable working position
- In addition to comfort, the angle also allows for better sight lines when working in confined spaces – being able to see what you are cutting is critical in getting the job done quickly, accurately and efficiently
- Precision-ground stainless steel blades with fine serrations offer a clean and non-slip cut
- Two end ferrule crimping areas – one for 10 - 20 AWG and one for 4 - 8 AWG
- Includes opening spring and lock for easy storage and transport
- Additional wire cutter located in front of the slide lock
- Tether attachment point can be used with KNIPEX Tethered Tools System
- Durable belt pouch (00 19 75 LE) sold separately
- Cutting edges made from stainless steel, hardness of cutting edges 56 HRC
- Handles with multi-component grips, fiberglass reinforced plastic
| Specification(s) | |
|---|---|
| Part Number | 95 05 20 US |
| UPCs | 843221028619 |
| COO | Taiwan |
| Harmonized Tariff Code | 8203.30.0000 |
| ECCN | EAR99 |
| UNSPSC | 27111506.0 |
| Nominal Length | 6 1/4" |
| Tool Width | 3 1/8" |
| Tool Height | 1 3/16" |
| Tool Weight | 0.42 |
| Packaging Length | 7 1/4" |
| Packaging Width | 3" |
| Packaging Height | 1 3/8" |
| Packaging Weight | 0.46 |
| 1000 Volt Insulated | No |
| Material Type | Stainless steel cutting edges |
| Handle Type | Multi-component, fiberglass reinforced plastic |
| Spring Loaded | Yes |
| ESD Indicator | No |
| Color | Red/Blue |
| Blade Length | 1 1/4" |
| Cutting Edge HRC | 56 HRC |
| Angled Head | 45 degrees |
| Crimping Positions | 2 |
| Terminal Type | End Ferrules-Single (Insulated) |
| Crimping Capacity - AWG | 10 - 20 AWG (small crimper) and 4 - 8 AWG (large crimper) |
| Reach | does not contain SVHC |
| RoHS | not applicable |
| Tool Width-Decimal | 3.13" |
| Tool Height-Decimal | 1.19" |
Angled Electricians' Shears. The 45° angled shears provides a natural extension of your hand which offers a more comfortable working position.
