KNIPEX - 6 1/4" StepCut Cable Shears - Dipped Handle
KNIPEX - 6 1/4" StepCut Cable Shears - Dipped Handle
$35.14
/ Each
SKU
#KN-12070775
Part #:
9511160
Ships in 3-4 Days
- Cable cutting made easy: innovative step cutting separates and cuts one by one
- Small, light, strong: comfortable cutting without crushing and just 6 1/4" in length
- The cutting edge gradations cut wires one after the other making cutting 40% easier than with standard cable shears of the same length
- Cuts multi-core stranded copper and aluminum cables, single and multi-stranded wire up to 1/0 AWG
- Not suitable for steel wire and hard drawn copper conductors
- Easy cutting with one-hand operation
- Adjustable bolted joint provides precise and smooth cutting
- Pinch guard prevents operators' fingers being pinched
- Induction hardened cutting edges (approx. 56 HRC)
- High-grade special tool steel; forged, oil-hardened
| Specification(s) | |
|---|---|
| Part Number | 95 11 160 |
| Video Link | https://youtu.be/MPu5fIl2e4k |
| UPCs | 843221027681 |
| COO | Germany |
| Harmonized Tariff Code | 8203.30.0000 |
| ECCN | EAR99 |
| UNSPSC | 23241616.0 |
| Nominal Length | 6 1/4" |
| Tool Width | 1 1/2" |
| Tool Height | 3/8" |
| Tool Weight | 0.4 |
| Packaging Length | 6 1/2" |
| Packaging Width | 2" |
| Packaging Height | 1" |
| Packaging Weight | 0.431 |
| 1000 Volt Insulated | No |
| Material Type | High-grade special tool steel, forged, oil-hardened |
| Handle Type | Plastic coating |
| Handle Length | 4" |
| Color | Red |
| Cutting Edge Shape | Shear |
| Cutting Capacity - Cu and Al conductor | 9/16" |
| Cutting Edge HRC | Approx. 56 HRC |
| Reach | does not contain SVHC |
| RoHS | not applicable |
| Data Sheet | https://s3-us-west-2.amazonaws.com/catsy.534/95+1X+160+StepCut+Data+Sheet.pdf |
| Tool Nominal Length-Decimal | 6.25" |
| Tool Width-Decimal | 1.5" |
| Tool Height-Decimal | 0.375" |
Safety Data Sheets (PDF , 0B)
StepCut Cable Shears. Cable cutting made easy: innovative step cutting separates and cuts one by one.
