20" 1Ph 16-Spd Floor Step Pulley Drill Press
20" 1Ph 16-Spd Floor Step Pulley Drill Press
In stock
$2,251.00
/ EA
SKU
#PLG-9680209
Part #:
80209
Ships in 2-3 Days
| Specification(s) | |
|---|---|
| Country of Origin | CN |
| UPC | 726896802091 |
| Retail Height (inches) | 12.7 |
| Retail Length (inches) | 58.0 |
| Retail Width (inches) | 29.0 |
| Retail Weight (lbs) | 352.0 |
| Shipping Height | 70.0 |
| Shipping Length | 30.0 |
| Shipping Width | 19.5 |
| Shipping Weight | 274.0 |
| AMPS | 14.2/7.1 |
| Capacity Cast Iron | 1-1/4" |
| Drill Press Model | Floor Model |
| Drill Press Type | Step Pulley |
| Maximum Spindle to Table | 26" |
| Motor HP | 1-1/2 |
| Overall Dimensions (LxWxH) | 70" H x 19-1/2" W x 30" D |
| Phase | Single |
| RPM | 120 -3605 |
| Spindle Taper | MT2/JT4 |
| Spindle Travel | 6.0 |
| Swing | 20" |
| Table Dimensions | 19-1/4" x 18-3/4" |
| Table Slots | 5/8" |
| Voltage | 120/240 |
| Warranty | 3 Year |
Palmgren’s step pulley drill presses are substantially constructed to provide a solid base for all your drilling operations, and offer a greater range of spindle speeds than any others in their class. They have the weight and rigidity to maintain the built-in tight tolerances required for metalworking applications.
