7" X 12" Horizontal Metal Cut Band Saw
7" X 12" Horizontal Metal Cut Band Saw
In stock
$2,536.00
/ EA
SKU
#PLG-9683311
Ships in 2-3 Days
| Specification(s) | |
|---|---|
| Country of Origin | TW |
| UPC | 726896833118 |
| Retail Height (inches) | 41.6 |
| Retail Length (inches) | 50.7 |
| Retail Width (inches) | 18.0 |
| Retail Weight (lbs) | 330.0 |
| Shipping Height | 41.6 |
| Shipping Length | 50.7 |
| Shipping Width | 18.0 |
| Shipping Weight | 330.0 |
| AMPS | 12/6.0 |
| Cold Saw and Band Saw Saw Type | Semi-Automatic |
| Coolant | Flood |
| Cutting Angle | 45° |
| Cutting Capacity | 7" x 11-3/4" rectangle |
| Cutting Capacity.1 | 7" round |
| Cutting Capacity.2 | 7" square |
| Frequency of Use | Intermittent Use,Light Production (Less than 25%of work day) |
| Includes | operators manual, chip screen, 4 wheels, 2 axle shafts, heavy duty work stop, drive belt cover |
| Manual Horizontal Band Saw Type | Single miter |
| Material to be Cut | Ferrous Metals, Non-Ferrous Metals, Composites, Plastics |
| Max. Thickness of Cut | 7" |
| Motor HP | 1 |
| Number of Spindle Speeds | 96-132-178-260 FPM |
| Optional Accessories | 9683331 - Replacement Blade – Bi-Metal, 3/4" x 0.035" x 6-10 TPI |
| Overall Dimensions (LxWxH) | 41" x 18" x 45" |
| Phase | Single |
| RPM | 1725 |
| Sawing Type | Horizontal Band Saws |
| Type of Cutting | Angle/Miter, Contour, Cutting-Off, Pattern/Cutting Out/Notching, Ripping,Single Piece, Stacking,Straight |
| Voltage | 120/240 |
| Warranty | 3 Year |
Palmgren’s 7" x 12" horizontal band saw is the ideal saw for machine maintenance and fabricating shops and for limited run production applications. Heavy duty rigid steel and cast iron construction of the saw head and base provide full blade support and eliminates vibration and deflection.
