3M™ Scotchcast™ Electrical Resin 265, 50 lb, 1/Case

3M™ Scotchcast™ Electrical Resin 265, 50 lb, 1/Case

SKU
#7000006256
Part #: 34522
Call for Availability
For industrial/occupational use only. Not for consumer sale or use.

For industrial/occupational use only. Not for consumer sale or use.


3M industrial and occupational products are intended, labeled, and packaged for sale to trained industrial and occupational customers for workplace use. Unless specifically stated otherwise on the applicable product packaging or literature, these products are not intended, labeled, or packaged for sale to or use by consumers (e.g., for home, personal, primary or secondary school, recreational/sporting, or other uses not described in the applicable product packaging or literature), and must be selected and used in compliance with applicable health and safety regulations and standards (e.g., U.S. OSHA, ANSI), as well as all product literature, user instructions, warnings, and other limitations, and the user must take any action required under any recall, field action, or other product use notice. Misuse of 3M industrial and occupational products may result in injury, sickness, death, or property damage. For help with product selection and use, consult your on-site safety professional, industrial hygienist, or other subject matter expert.


3M™ Scotchcast™ Resin 265 is a 1 part, general purpose, epoxy based, rapid cure, powder resin. It is manufactured by a fusion blend process while ensuring that each particle of powder contains all the components necessary to effect a complete cure and attain stated performance properties. The 100% solid insulation offers enhanced adhesion, thermal and electrical properties.
More Information
Specification(s)
Part number265
UPC Code00054007345220
Applicable by Electrostatic Fluid BedNo
Applicable by Electrostatic SprayNo
Applicable by Fluid Bed DipYes
Applicable by Venturi SprayYes
ApplicationUtilities & Power: Coatings for Insulation
Color FamilyGreen
Cure MethodOven
Flame RetardantYes
FlexibilityRigid
FormPowder
MaterialEpoxy
Mining Sector ApprovalNo
Net Weight (Imperial)50.0 lb
Product ColorGreen
Product TypeElectrical Resin
Resin MatrixUnfilled
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Storage Time in Months24.0
Temperature RatingClass H (<=180 deg C)
What Needs to be CoatedWound assembly (coil impregnation)
Country of OriginUSA
Unit of Use - Customary Net Weight1.0 LBS
Shipping Quantity50.0
Brand3M
no_image
Safety Data Sheets (PDF , 0B)

3M™ Scotchcast™ Electrical Resin 265 has a low melt viscosity and minimum build that is ideal for a variety of coating, bonding and saturation applications. It is a widely used, well known, general purpose epoxy powder resin. The non flammable resin does not contain any solvents and does not require any mixing or catalyzation. This odor free resin can be applied by trickle, spray or dip processes, and is simply applied to the heated windings where it melts, flows into the wire interstices and cures. ASTM Approved and RoHS 2011/65/EU Compliant.


  • Solids insulation renders good adhesion, thermal and electrical properties
  • Has 60-second gel time at 379.4 °F (193 °C)
  • For a variety of coating, bonding and saturation applications
  • Withstands temperatures of 356 °F (180 °C)
  • Applied by trickle, spray or dip processes
  • Provides excellent electrical properties and thermal shock resistance
