3M™ Adhesive Transfer Tape 9457, Clear, 3 in x 60 yd, 1 mil, 4 Roll/Case

Name: 3M™ Adhesive Transfer Tape 9457, Clear, 3 in x 60 yd, 1 mil, 4 Roll/Case
Brand: 3M
SKU: 7010302077

SKU

#7010302077

Part #: 74193

Call for Availability

For industrial/occupational use only. Not for consumer sale or use.

3M industrial and occupational products are intended, labeled, and packaged for sale to trained industrial and occupational customers for workplace use. Unless specifically stated otherwise on the applicable product packaging or literature, these products are not intended, labeled, or packaged for sale to or use by consumers (e.g., for home, personal, primary or secondary school, recreational/sporting, or other uses not described in the applicable product packaging or literature), and must be selected and used in compliance with applicable health and safety regulations and standards (e.g., U.S. OSHA, ANSI), as well as all product literature, user instructions, warnings, and other limitations, and the user must take any action required under any recall, field action, or other product use notice. Misuse of 3M industrial and occupational products may result in injury, sickness, death, or property damage. For help with product selection and use, consult your on-site safety professional, industrial hygienist, or other subject matter expert.

3M™ Adhesive Transfer Tape 9457 offers instant adhesion to metals, glass, wood, papers and plastics. It features an easy liner release for both manual and hand applications, which makes it a perfect choice for high-speed flying spices and zero splices on most grades of paper in commercial print applications.

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Specifications

More Information
Specification(s)
UPC Code	00021200741937
Adhesive Type	Acrylic
Color Family	Transparent
Maximum Operating Temperature (Fahrenheit)	250.0 Degree Fahrenheit
Minimum Operating Temperature (Fahrenheit)	-60.0 Degree Fahrenheit
Overall Length (Imperial)	60.0 yd
Overall Width (Imperial)	3.0 in
Primary Liner	55# Densified Kraft Paper
Primary Liner Thickness (Imperial)	3.2 mil
Product Number	9457
Specifications Met	MIL-P-19834B, Type I
Substrate 1	Glass (Inked Glass - Ceramic)
Substrate 2	Paper (Coated - Corrugated - Uncoated)
Total Tape Thickness without Liner (Imperial)	1.0 mil
Country of Origin	USA
Unit of Use - Customary Net Weight	1.019 LBS
Shipping Quantity	4.0
Brand	3M

Product Information

Offers High UV, Humidity and Moisture Resistance

3M™ Adhesive Transfer Tape 9457 helps keep production processes moving rapidly. Splicing foils, fabrics, films and papers has never been easier. This 1 mil, high-tack adhesive tape features an aggressive bond that adheres on contact. It has high UV, humidity and moisture resistance, and good solvent resistance. By using a robust 55 lb. densified kraft paper release liner, this tape provides reliable performance for industrial applications, such as die-cutting and automated dispensers.

Recommended Applications

High-speed flying splices and zero speed splices on most grades of paper

Splicing foils, films and fabrics

Laminating adhesive for foams and photos

Attaching metal and plastic nameplates

Mounting promotional items and posters

Core starting

3M™ Adhesive 400 Provides Good Holding Power

3M™ Adhesive Transfer Tape 9457 features aggressive 3M™ Adhesive 400, formulated for quick adhesion and good shear strength and holding power. This high performance adhesive offers a consistently strong bond in temperatures up to 250°F/121°C on a variety of substrates including metal, glass, wood, paper, paint and many plastics.

Understanding Adhesive Transfer Tapes

3M adhesive transfer tapes are rolls of pressure sensitive adhesive provided on a special release liner. The tape consists of an adhesive layer only, and does not have any type of supporting carrier such as film, paper or tissue. For application the tape is positioned adhesive side down to a surface and the liner is removed, exposing the backside adhesive to the joining surface.

Bringing Better Ideas to the Surface through Science and Innovation

The 3M Industrial Adhesives and Tapes Division applies the science of adhesion to deliver innovative solutions that improve the design and manufacturing processes of companies around the world. In the end, these technologies help customers deliver competitive products to the market faster and more efficiently.

Bonds a wide variety of substrates including metal, glass, wood, paper, paint and many plastics

55 lb. unbleached densified kraft liner allows for manual or hand applications

3M™ Adhesive 400 offers consistently strong bonds in temperatures up to 250°F/121°C

Includes easy liner release for manual or hand application

Designed for use with sub-surface graphics printing on polyester films and custom tamper-indicating labels
