3M™ Double Coated Tissue Tape 9456, Clear, 3/4 in x 72 yd, 4 mil, 48 Roll/Case
3M™ Double Coated Tissue Tape 9456, Clear, 3/4 in x 72 yd, 4 mil, 48 Roll/Case
| Specification(s) | |
|---|---|
| UPC Code | 00021200406119 |
| Adhesive Type | Adhesive 340 |
| Backing (Carrier) Material | Tissue |
| Back Side Adhesive Thickness (Imperial) | 2.0 mil |
| Back Side Adhesive Type | High Tack Acrylic Adhesive 340 |
| Color Family | Transparent |
| Face Side Adhesive Thickness (Imperial) | 2.0 mil |
| Face Side Adhesive Type | High Tack Acrylic Adhesive 340 |
| Indoor/Outdoor | Indoor/Outdoor |
| Maximum Operating Temperature (Fahrenheit) | 180.0 Degree Fahrenheit |
| Minimum Operating Temperature (Fahrenheit) | -40.0 Degree Fahrenheit |
| Overall Length (Imperial) | 72.0 yd |
| Overall Width (Imperial) | 0.75 in |
| Primary Liner | 55# Densified Kraft Paper (DK) |
| Primary Liner Color | White |
| Primary Liner Thickness (Imperial) | 3.5 mil |
| Product Color | Transparent |
| Product Form | Roll |
| Product Number | 9456 |
| Total Tape Thickness without Liner (Imperial) | 4.0 mil |
| Country of Origin | USA |
| Unit of Use - Customary Net Weight | 0.248 LBS |
| Shipping Quantity | 48.0 |
| Brand | 3M |
Light Carrier, High Tack
The 3M™ Double Coated Tissue Tape 9456 is a 5.0 mil tape with a 340 high tack acrylic adhesive that delivers a good bond for attaching foam to plastics and other substrates. This tape also has a tissue carrier for dimensional stability and improved handling, while still maintaining the flexibility of a free film adhesive. The tissue carrier is on a 3.2 mil 55-lb. densified Kraft DK paper liner. Use this tape in a variety of applications, especially those requiring adhesion to high surface energy (HSE) materials.
Recommended Applications
End-tabbing
Bonding fabric to rigid cardboard
Attaching foam to plastics
Closing chipboard mailers
Joining and bonding in general industrial applications
About 3M™ Adhesive 340
Like other 3M™ Double Coated Tapes offered by 3M, this product uses Adhesive 340, which delivers a combination of high initial adhesion, good shear strength and holding power when applied to a wide variety of materials, including plastics and foams. Additionally, the 340 adhesive in 3M™ Double Coated Tissue Tape 9456 provides excellent chemical and thermal resistance and can be used in a wide range of temperatures and demanding work conditions. Use this tape in temperatures ranging from -40°F (-40°C) to 150°F (66°C). Collectively, these features make this tape an excellent option for a number of applications across many industries, including: paper, converter solutions, automotive, medical, general industrial, retail, print, point of purchase and packaging.
What is Double Coated Tape?
In general, double coated tape is composed of a paper, film, or tissue carrier that is coated on both sides with pressure sensitive adhesive. The adhesive is protected by a peel-away liner that is removed at the time of application. These tapes can be applied by hand or with a dispenser. Double coated tape dispensers are available in a variety of configurations ranging from manual to fully automatic. Applications for double coated tape are found in electronics, automotive, aerospace, general industrial, and fabrication markets.
Bringing Better Ideas to the Surface through Science
3M Industrial Adhesives and Tapes Division applies the science of adhesion to deliver innovative solutions that improve the design and manufacturing processes of companies around the world. In the end, these technologies help customers deliver competitive products to the market faster and more efficiently.
