3M™ Double Coated Tape 9500PC, Clear, 1 1/2 in x 36 yd, 5.6 mil, 24 Roll/Case

Name: 3M™ Double Coated Tape 9500PC, Clear, 1 1/2 in x 36 yd, 5.6 mil, 24 Roll/Case
Brand: 3M
SKU: 7000123456

SKU

#7000123456

Part #: 86295

Call for Availability

For industrial/occupational use only. Not for consumer sale or use.

3M industrial and occupational products are intended, labeled, and packaged for sale to trained industrial and occupational customers for workplace use. Unless specifically stated otherwise on the applicable product packaging or literature, these products are not intended, labeled, or packaged for sale to or use by consumers (e.g., for home, personal, primary or secondary school, recreational/sporting, or other uses not described in the applicable product packaging or literature), and must be selected and used in compliance with applicable health and safety regulations and standards (e.g., U.S. OSHA, ANSI), as well as all product literature, user instructions, warnings, and other limitations, and the user must take any action required under any recall, field action, or other product use notice. Misuse of 3M industrial and occupational products may result in injury, sickness, death, or property damage. For help with product selection and use, consult your on-site safety professional, industrial hygienist, or other subject matter expert.

3M™ Double Coated Tape 9500PC is a 5 mil (0.14 mm) 350 high performance acrylic adhesive double coat with a thin polyester carrier film on a 58#, 4.5 mil unprinted, polycoated kraft paper liner. The adhesive excels on low surface energy (LSE) substrates and at high temps.

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Specifications

More Information
Specification(s)
UPC Code	00021200862953
Backing (Carrier) Material	Polyester
Backing (Carrier) Thickness (Imperial)	1.0 mil
Back Side Adhesive Thickness (Imperial)	2.3 mil
Back Side Adhesive Type	High Performance Acrylic Adhesive 350
Color Family	Transparent
Face Side Adhesive Thickness (Imperial)	2.3 mil
Face Side Adhesive Type	High Performance Acrylic Adhesive 350
Indoor/Outdoor	Indoor/Outdoor
Maximum Operating Temperature (Fahrenheit)	350.0 Degree Fahrenheit
Minimum Operating Temperature (Fahrenheit)	-40.0 Degree Fahrenheit
Overall Length (Imperial)	36.0 yd
Overall Width (Imperial)	1.5 in
Primary Liner	62# Polycoated Kraft Paper
Primary Liner Color	Tan
Primary Liner Thickness (Imperial)	4.5 mil
Product Color	Transparent
Product Number	9500PC
Total Tape Thickness without Liner (Imperial)	5.6 mil
Country of Origin	USA
Unit of Use - Customary Net Weight	0.677 LBS
Shipping Quantity	24.0
Brand	3M

Product Information

3M™ Double Coated Tape 9500PC has a 1.0 mil polyester carrier for improved dimensional stability and handling – especially in die cutting and laminating applications. This tape can be used to laminate high performance plastics and difficult substrates, while delivering broad temperature resistance. Toward that end, this tape can be used in temperatures ranging from -40°F (-40°C) to 350°F (177°C). Additionally, users enjoy medium UV resistance, helping to expand the durability and longevity of this product.

Recommended Applications

Bonding low surface energy (LSE) plastics such as polypropylene and polyethylene

High temperature applications

Die cutting

Laminating

The 350 Advantage

3M™ Adhesive 350 family is a medium-firm acrylic adhesive that provides excellent shear holding power and initial adhesion; as well as high wet grab, temperature and UV resistance. The liner reduces edge burr during hard tool die cutting, improving accuracy and potentially improving throughput. Collectively, these features make this tape suitable for use in various applications across different industries, including: converter solutions, transportation, specialty vehicle, metalworking, automotive, oil and gas, medical, signage, military and government, general industrial, appliance and electronics.

Clear, 5 mil (0.14 mm) double coated tape with high performance acrylic

1.0 mil, clear PET carrier film for dimensional stability and ease of die cutting

Adheres to powder coated surfaces, most plastics and difficult surfaces

High-holding strength and short-term heat resistance up to 350°F (177°C)

58# unprinted polycoated kraft liner reduces edge burr during hard tool die cutting
