Scotch® Vinyl Electrical Tape 66R, 3/4 in x 36 yd, Black, 48 rolls/Case

Scotch® Vinyl Electrical Tape 66R, 3/4 in x 36 yd, Black, 48 rolls/Case

SKU
#7000132758
Part #: 43249
Call for Availability
For industrial/occupational use only. Not for consumer sale or use.

For industrial/occupational use only. Not for consumer sale or use.


3M industrial and occupational products are intended, labeled, and packaged for sale to trained industrial and occupational customers for workplace use. Unless specifically stated otherwise on the applicable product packaging or literature, these products are not intended, labeled, or packaged for sale to or use by consumers (e.g., for home, personal, primary or secondary school, recreational/sporting, or other uses not described in the applicable product packaging or literature), and must be selected and used in compliance with applicable health and safety regulations and standards (e.g., U.S. OSHA, ANSI), as well as all product literature, user instructions, warnings, and other limitations, and the user must take any action required under any recall, field action, or other product use notice. Misuse of 3M industrial and occupational products may result in injury, sickness, death, or property damage. For help with product selection and use, consult your on-site safety professional, industrial hygienist, or other subject matter expert.


Scotch® Tape 66R is a 10 mil thick, premium grade, conformable electrical tape. It provides electrical, mechanical and moisture protection with the combination of elastic, PVC backing and a pressure sensitive, rubber resin adhesive. This flame retardant tape is designed to provide electrical insulation for 600V bus bar applications.
More Information
Specification(s)
Part number66R-3/4X36YD-K
UPC Code00054007432494
Adhesive TypeRubber
ApplicationElectrical Maintenance
Backing (Carrier) MaterialPVC
Elongation at Break250.0 %
Flame RetardantYes
Maximum Operating Temperature (Fahrenheit)220.0 Degree Fahrenheit
Overall Length (Imperial)36.0 yd
Overall Width (Imperial)0.75 in
Product ColorBlack
Shelf Life5.0 Year
Total Tape Thickness without Liner (Imperial)10.0 mil
Voltage Rating600 V
Country of OriginUSA
Unit of Use - Customary Net Weight0.196 LBS
Shipping Quantity48.0
Brand3M

Scotch® Tape 66R Electrical Tape provides a protective jacket for high voltage cable splices. It is highly resistant to abrasion, moisture, alkalis, acid and varying weather conditions. This tape is compatible with solid, dielectric cable insulation. It is suitable for jacketing low and high voltage bus bar. It withstands a temperature range of 32 to 221 °F (0 to 105 °C). UL Listed and RoHS 2011/65/EU Compliant.


  • VERSATILE APPLICATION: For use as a dielectric insulating component for motors, coils, and transformers, or to function as electrical insulation in appliances or devices
  • EFFECTIVE ELECTRICAL PROTECTION: Meets the UL510A standard and is temperature rated to 221 °F (105 °C)
  • BUILT STRONG: Made with an elastic vinyl (PVC) film backing and noncorrosive rubber-based pressure-sensitive adhesive
  • MULTI-PURPOSE: Functions as electrical and mechanical protection in electro-mechanical products
  • FLAME RETARDANT: Meets UL 510A standards as flame retardant
  • KEY SPECIFICATIONS: UL Component Recognized and RoHS Compliant
