3M™ Double Coated Film Tape 9589, White, 1 in x 36 yd, 9 mil, 36 Roll/Case
3M™ Double Coated Film Tape 9589, White, 1 in x 36 yd, 9 mil, 36 Roll/Case
| Specification(s) | |
|---|---|
| UPC Code | 00021200232053 |
| Backing (Carrier) Material | HDPE |
| Backing (Carrier) Thickness (Imperial) | 0.178 mil |
| Back Side Adhesive Thickness (Imperial) | 3.0 mil |
| Back Side Adhesive Type | Synthetic Rubber Adhesive 760 |
| Carrier Material | High Density Polyethylene HDPE |
| Carrier Thickness | 0.178472222222222 mil |
| Color Family | White |
| Core Size (Imperial) | 3.0 in |
| Face Side Adhesive Thickness (Imperial) | 3.0 mil |
| Face Side Adhesive Type | Synthetic Rubber Adhesive 760 |
| Indoor/Outdoor | Both |
| Maximum Operating Temperature (Fahrenheit) | 120.0 Degree Fahrenheit |
| Minimum Operating Temperature (Fahrenheit) | -40.0 Degree Fahrenheit |
| Overall Length (Imperial) | 36.0 yd |
| Overall Thickness (Imperial) | 3.0 mil |
| Overall Width (Imperial) | 1.0 in |
| Primary Liner | 62# Densified Kraft Paper (DK) |
| Primary Liner Color | White/Green |
| Primary Liner Thickness (Imperial) | 3.7 mil |
| Product Color | White |
| Product Form | Roll |
| Product Number | 9589 |
| Substrate | Cardboard |
| Substrate 1 | Paper (Coated - Corrugated - Uncoated) |
| Substrate 2 | Rubber (SBR) |
| Total Tape Thickness without Liner (Imperial) | 9.0 mil |
| Country of Origin | USA |
| Unit of Use - Customary Net Weight | 0.584 LBS |
| Shipping Quantity | 36.0 |
| Brand | 3M |
Long-Lasting Performance
3M™ Double Coated Film Tape 9589 is a 9.0 mil double coated tape with a high tack synthetic rubber adhesive on a high density polyethylene (HDPE) carrier. 3M™ Adhesive 760 provides excellent quick stick and bonds together a wide variety of materials, with a build-up over 24 hours that allows for proper placement of bonded materials. It features excellent adhesion to both high surface energy and low surface energy substrates and is an excellent choice for many indoor and room temperature applications such as carpet installation. The HDPE carrier adds dimensional stability to aid in removal while also providing easier handling during slitting, lamination and die cutting, and it tears by hand for quick and easy application. The tape is mounted on a 3.7 mil 62 lb. densified kraft paper liner which has been specially treated to improve strength and removability from high internal strength surfaces. This tape can withstand short-term temperatures of up to 200°F.
Recommended Applications
Carpet installation
General industrial mounting, joining and splicing
Miscellaneous joining and holding where high initial tack is required
Die-cutting and laminating applications
