3M™ Polyester Protective Tape 335, Pink, 8 in x 144 yd, 1.6 mil, 1 Roll/Case

Name: 3M™ Polyester Protective Tape 335, Pink, 8 in x 144 yd, 1.6 mil, 1 Roll/Case
Brand: 3M
SKU: 7010045173

SKU

#7010045173

Part #: 39367

Call for Availability

For industrial/occupational use only. Not for consumer sale or use.

3M industrial and occupational products are intended, labeled, and packaged for sale to trained industrial and occupational customers for workplace use. Unless specifically stated otherwise on the applicable product packaging or literature, these products are not intended, labeled, or packaged for sale to or use by consumers (e.g., for home, personal, primary or secondary school, recreational/sporting, or other uses not described in the applicable product packaging or literature), and must be selected and used in compliance with applicable health and safety regulations and standards (e.g., U.S. OSHA, ANSI), as well as all product literature, user instructions, warnings, and other limitations, and the user must take any action required under any recall, field action, or other product use notice. Misuse of 3M industrial and occupational products may result in injury, sickness, death, or property damage. For help with product selection and use, consult your on-site safety professional, industrial hygienist, or other subject matter expert.

3M™ Polyester Protective Tape 335 is a thin, pink colored, polyester film tape with a low tack rubber adhesive. It is designed to protect polished metal and plastic surfaces during production, packing, shipping and installation with minimal adhesion build-up and clean removal.

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Specifications

More Information
Specification(s)
UPC Code	00021200393679
Adhesion Strength (Imperial)	13.0
Adhesive Type	Rubber
Application	Surface Protection, Painting & Depainting
Backing (Carrier) Material	Polyester
Backing (Carrier) Thickness (Imperial)	0.94 mil
Backing Material	Polyester
Backing Thickness (Imperial)	0.9 mil
Color Family	Pink
Elongation at Break	115
Maximum Operating Temperature (Fahrenheit)	150.0 Degree Fahrenheit
Minimum Operating Temperature (Fahrenheit)	40.0 Degree Fahrenheit
Overall Length (Imperial)	144.0 yd
Overall Thickness (Imperial)	1.5 mil
Overall Width (Imperial)	8.0 in
Product Color	Pink
Product Form	Roll
Product Number	335
Tensile Strength (Imperial)	26.0 lb/in
Total Tape Thickness without Liner (Imperial)	1.6 in
Country of Origin	MEXICO
Unit of Use - Customary Net Weight	3.109 LBS
Shipping Quantity	1.0
Brand	3M

Product Information

Thin, Visible Surface Protection

3M™ Polyester Protective Tape 335 is a 1.5 mil, polyester film tape designed to protect finished surfaces from light abrasion, nicks and scratches. The pink colored tape provides a clear and definitive identification of the protective area, while also providing visibility for application or removal. This tape offers excellent heat, abrasion, tear, scratch, impact and puncture resistance. It can withstand extended exposure to temperatures up to 150°F/66°C, and short term (30 minutes or less) exposure up to 250°F/121°C.

Recommended Applications

Protection from fumes and splash during plating processes on the upper portion of printed wiring boards

Protection of polished stainless steel and aluminum in fabrication, shipping and storage

Protection of nameplates and instrument panels during shipping and installation

Protection of finished, non-metallic surfaces

Protection of non-image side of inner layers of multi-layer printed wiring boards

Low-Tack Adhesion with Minimal Build-Up

3M™ Polyester Protective Tape 335 features a low tack, clear, rubber adhesive that adheres to a wide variety of surfaces, including polished metal and plastic surfaces. This adhesive features minimum adhesion build-up and removes easily and cleanly, even when used on large surfaces. It won't mar or leave sticky residue behind, making it ideal for finished surfaces. Extended exposure to direct sunlight, high stacking pressures and extended application to copper bearing surfaces may increase adhesion levels.

Low tack rubber adhesive adheres to a wide variety of surfaces with minimal adhesion build-up and clean removal when finished, even on large surfaces

Extensible, abrasion resistant backing is ideal for forming operations

Pink color provides easy visibility for either application or removal, providing quick identification of protected versus unprotected areas

Provides excellent abrasion, tear, scratch, puncture and moisture resistance to help protect surfaces

Performs at temperatures up to 150°F/66°C for extended periods of time

Hand-moldable feature allows for easy application (no special tools or damming required)
