Comb. Bench & Pipe Vise, 5.5"

Name: Comb. Bench & Pipe Vise, 5.5"
Brand: Palmgren
SKU: PLG-9629755

In stock

$618.00

/ EA

SKU

#PLG-9629755

Ships in 2-3 Days

California Proposition 65

Straight line power tunnel design - unbreakable spindle & nut with increased clamping power.

Enclosed construction keeps lubrication in & contaminants out, making it ideal for both indoor & outdoor use.

Hardened replaceable steel jaw inserts ensures positive hold.

Hardened replaceable steel self-centering pipe jaws hold round materials securely.

Extra deep throat gives you more working room where it counts.

Locking swivel base with double lockdowns for non-slip hold in any position.

Precision side bar machined for a .

002" fit.

Oversized machined anvil provides structural integrity and consistent properties of toughness and hardness for greater working area.

ULTRA STRONG, the entire vise is made of 65,000 PSI ductile iron - coupled with our exclusive manufacturing process of the body and nut – delivers a vise that is 50% stronger than all gray iron vises and 20% stronger than competitive ductile iron vises.

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Specifications

More Information
Specification(s)
Country of Origin	TW
UPC	726896297552
Retail Height (inches)	11.5
Retail Length (inches)	18.0
Retail Width (inches)	11.0
Retail Weight (lbs)	55.0
Anvil Length x Width	3-1/2" x 5-3/4"
Jaw Opening	8-1/2"
Jaw Type	Replaceable
Jaw Width	5-1/2"
Material	Ductile Iron
Max. Jaw Opening	5.75 in
Mounting Hole	.5 in
Overall Dimensions (LxWxH)	16" x 10" x 10"
Pipe Jaw Capacities	1/4" – 3-1/2"
Throat Capacity	3.75 "
Vise Material	Ductile
Vise Type	Bench Vises
Warranty	Limited Lifetime

Product Information

The Palmgren 5.5 -in Comb. Bench & Pipe Vise houses a super strong power tunnel with straight-line pull that assures a lifetime spindle and nut never to wear out. A precision fit of the slide bar eliminates side play and jaw wobble even when clamping with the jaws wide open. The vise spindle and nut are totally enclosed in a square tube casting that protects them from dust, chips and moisture, keeping them lubricated for life.
